Use Case 01: Redirect http to https traffic

Prerequisites

This usecase assumes that a F5 BIG-IP instance, webservers and Ansible node are deployed. To deploy infrastructure in AWS users can use the F5 Ansible Provisioner

Overview of Use Case

Challenge: When a BIG-IP has multiple Virtual IPs (VIPs) configured, it can be tedious to implement an SSL redirect from standard HTTP traffic for each Virtual IP.

F5-LTM-HTTP-Redirect.yml playbook will create an SSL VIP then create the associative Port 80 SSL redirect for that VIP.

In this example, the playbook looks for F5_VIP_Name: ‘Use-Case-1-VIP’ as specified in the f5_vars.yaml variable file. Users can modify this variable file to create redirect service for any other VIP.

Note

This will loop through the entire VIP list so this could take time depending on the number of VIPs within your BIG-IP

Use Case Setup

  1. Login to the Ansible Host

  2. Run the Ansible Playbook ‘F5-LTM-HTTP-Redirect.yml’ with the variable file ‘f5_vars.yml’ :

    cd ~/f5_ansible_use_cases/01-deploy-redirect
ansible-playbook F5-LTM-HTTP-Redirect.yml -e @f5_vars.yml

  3. Testing and Validating

    • Login to the BIG-IP
    • Navigate to Local traffic->Virtual server
    • Ensure there are 2 VIPs with same IP
      • One listening on port 443
      • One listening on port 80
    • Access the VIP on port 80 you will be redirected to 443 (http://VIP:80)
    • The same webpage will also be accessible via VIP:443 (https://VIP:443)

    Note

    The IP address shown will differ from your IP address, make sure to use your own inventory file


    _images/UseCase1-960.gif

    Note

    While accessing the Virtual IP, your browser is presented with a certificate (clientssl cert) that is built with the BIG-IP. You will therefore see an ‘unsafe’ message. Click proceed to website.
